20UPGFC0142219

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142219
ProdDB ID	60b329…e999d4
LocalDB ID	660d7cb7ec873d0035450ff9
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: LP_MODE QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	660d7cb7ec873d0035450ff9
Stage	MODULE/INITIAL_WARM
Test Type	LP_MODE
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	68926e1f8428c598c032ba54
ObjectId of RAW record	68926e1d8428c598c032ba4d
Tags	No tags
