20UPGFC0142214

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142214
ProdDB ID	607f03…411a8f
LocalDB ID	660d7cafec873d0035450fe5
Component Type	fe_chip
Parents	20UPGM23210791 20UPGB43200170
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d7cafec873d0035450fe5
Stage	MODULE/FINAL_COLD
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	GiordonStark
ObjectId of this record	68dc7e4d95403e048c93e312
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-10-01T00:20:07.000+00:00
MEASUREMENT_DURATION	2705
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
PIXEL_FAILURE_BAD_ANALOG	4
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	5
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	4
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	5
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	5
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	10
PIXEL_FAILURE_ELECTRICALLY_FAILED	65
PIXEL_FAILURE_FAILING_PIXELS	70
PIXEL_FAILURE_HIGH_ENC	3
PIXEL_FAILURE_HIGH_NOISE	12
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	True
PIXEL_FAILURE_TUNING_BAD	41

Attachments

Filename	Contents
0x22b86.log	Download
output.log	Download
20UPGFC0142214_MODULE__FINAL_COLD_PIXEL-FAILURE-ANALYSIS.zip	Download
