20UPGFC0142188

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142188
ProdDB ID	255ab4…86e0a8
LocalDB ID	660d7c882fc9f200350b6dd0
Component Type	fe_chip
Parents	20UPGM23210861 20UPGB43200172
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d7c882fc9f200350b6dd0
Stage	MODULE/FINAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	GiordonStark
ObjectId of this record	68d30dba736dd67ef24a869b
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-23T21:05:52.000+00:00
MEASUREMENT_DURATION	426
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_BAD_ANALOG_INTEGRATED	4
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_ANALOG	4
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	1
MIN_HEALTH_HIGH_ENC_INDEPENDENT	1
MIN_HEALTH_NOISE_MEAN	92.92
MIN_HEALTH_NOISE_SIGMA	11.58
MIN_HEALTH_THRESHOLD_FAILED_FITS	361
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	365
MIN_HEALTH_THRESHOLD_MEAN	2568.5
MIN_HEALTH_THRESHOLD_SIGMA	396.13
MIN_HEALTH_TOT_MEAN	8.98
MIN_HEALTH_TOT_SIGMA	2.31
