20UPGFC0142186

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142186
ProdDB ID	c8fb15…241f69
LocalDB ID	660d7c84ec873d0035450ef3
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d7c84ec873d0035450ef3
Stage	MODULE/FINAL_COLD
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	SamuelRoberts
ObjectId of this record	68cde5a54620977c2530f9fc
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-19T22:34:10.000+00:00
MEASUREMENT_DURATION	2715
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
PIXEL_FAILURE_BAD_ANALOG	5
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	3072
PIXEL_FAILURE_DEAD_ANALOG	2
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	3
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	3
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	3
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	3078
PIXEL_FAILURE_ELECTRICALLY_FAILED	3207
PIXEL_FAILURE_FAILING_PIXELS	3210
PIXEL_FAILURE_HIGH_ENC	5
PIXEL_FAILURE_HIGH_NOISE	12
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	True
PIXEL_FAILURE_TUNING_BAD	111

Attachments

Filename	Contents
0x22b6a.log	Download
output.log	Download
20UPGFC0142186_MODULE__FINAL_COLD_PIXEL-FAILURE-ANALYSIS.zip	Download
