20UPGFC0142133

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0142133
ProdDB ID	3184ff…ce3331
LocalDB ID	660d7c45ec873d0035450e36
Component Type	fe_chip
Parents	20UPGM23210036 20UPGB43200197
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	660d7c45ec873d0035450e36
Stage	MODULE/FINAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	Md ArifAbdullaSamy
ObjectId of this record	68bff71fdcbb9b92e8b21bb8
ObjectId of RAW record	68bff715dcbb9b92e8b21b69
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-09T09:02:05.000+00:00
MEASUREMENT_DURATION	335
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
AR_IREF_TRIM	10
AR_IREF	3.8e-06
AR_GADC	0.796
AR_NOMINAL_SETTINGS	[3.8e-06, 8.52e-05, 4.65e-05, 4e-06, 3.76e-05, 1.88e-05, 0, 3.67e-05, 6.99e-05, -999, 0, 0, 4.33e-05, 6.18e-05, 4.97e-05, 8.31e-05, 7.09e-05, 7.24e-05, 7.88e-05, 8.31e-05, 7.22e-05, 4.55e-05, 4.4e-05, 7.1e-05, 4.45e-05, 4.47e-05, -999, -999, 0.6139683, 0.0658829, 0.8654868, 0.2518653, 0.795629, -999, -999, 0.799046, 1.19768, 0.111474, 0.105735, 0.177136, 0.0355053, 0.0396436, 0.17345, 0.171728, 0.172715, 0.636257, -999, 0.633312, -999, 0.581401, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.016276, 0.458931, 1.9862984, 1.494532, 1.203456, 0.590602, 0.975924, 1.498092, 1.19614, 0.590757]
AR_ROSC_MAX_RESIDUAL	[2.73810103262256, 4.816783946679643, 2.632870445884571, 4.61539688079065, 1.9034371341978495, 3.3715675622804646, 2.0261065399914946, 3.276666343937326, 4.311607620450198, 4.206097726468683, 5.135448939951583, 5.034800329075307, 4.1414518151481134, 4.041701786644651, 4.805757017806465, 4.934151278516375, 3.196530353983822, 2.99394377882281, 3.4578471688033297, 3.564800414065096, 2.7324851863522213, 2.797152897021692, 3.7437829813357553, 3.8818777216670215, 2.4196575952484993, 2.312026716857538, 2.849196227071309, 2.6308533705516033, 2.9383705788168575, 2.954717067444601, 4.999413570478445, 5.876093385156976, 4.240102003376221, 4.474499422364862, 3.405927329234446, 3.4701818552922505, 3.3219157791589695, 3.501010477031075, 3.409198203678948, 3.4752684488853753, 3.413819632488803, 3.5635580665672166]
AR_ROSC_OFFSET	[-418.9569231838355, -635.1607544434023, -430.66209588306987, -654.7503700798901, -523.986839539516, -893.322138452601, -663.9215770576221, -958.8014701972609, -672.1503421561699, -674.0146287126138, -796.7289423063548, -791.8040076260098, -702.5953150563831, -705.8272205589391, -811.4722746184414, -814.3171175251061, -912.6828222473513, -894.2661112120448, -1063.1366465386157, -1059.278593306563, -932.5241526134877, -925.3251099701796, -1135.461535657135, -1134.9172941871645, -524.9540742828727, -517.8777221912125, -637.2406475049227, -639.2372874182712, -624.3836685633047, -620.2369133859625, -544.785263974797, -537.7821393278264, -595.3423485993062, -630.7799062436296, -1013.8184549385461, -1018.0390540784628, -1027.2400964106128, -1022.0177412569797, -1018.6581540366514, -1012.0075009533041, -1020.6990207117146, -1013.7024459636866]
AR_ROSC_SLOPE	[734.9593047120607, 1133.9237429779541, 731.868476101913, 1143.4620061966468, 801.0173113281538, 1370.014075875902, 960.4255014060835, 1405.102874269214, 1150.811312710864, 1144.1787467983688, 1349.691574372488, 1344.6153765926388, 1172.032925670258, 1171.478145279835, 1351.205737910855, 1355.4762956730444, 1381.0724749066749, 1340.9524041199377, 1596.3467941295635, 1602.6132416661974, 1339.8413827555996, 1334.1160945799973, 1661.369089621696, 1673.1460377315789, 833.6165492473159, 826.7923307237617, 1008.3954261653079, 998.9903105460758, 1002.8734903104943, 1000.0044371123485, 1119.685649982488, 1182.4868547575277, 1109.2299949539215, 1177.4367710405843, 1535.8666389494344, 1537.1519300638681, 1536.3108580989572, 1535.5112941653958, 1538.9355409398347, 1539.4236228530535, 1537.2329954434576, 1541.1872452959608]
AR_TEMP_ACB	26.439
AR_TEMP_ASLDO	27.165
AR_TEMP_DSLDO	28.386
AR_TEMP_EXT	19.26
AR_TEMP_NF_ACB	1.253
AR_TEMP_NF_ASLDO	1.255
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.254
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	19.638
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.799
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	6
AR_VDDA_VS_TRIM	[1.055, 1.079, 1.104, 1.129, 1.154, 1.178, 1.203, 1.228, 1.257, 1.282, 1.305, 1.33, 1.355, 1.379, 1.405, 1.428]
AR_VDDD_SATURATION	-1
AR_VDDD_TRIM	7
AR_VDDD_VS_TRIM	[1.035, 1.059, 1.082, 1.104, 1.126, 1.151, 1.173, 1.197, 1.226, 1.249, 1.273, 1.296, 1.318, 1.343, 1.367, 1.387]
AR_VREFCORE	0.459
AR_VREFOVP	1.986
