20UPGFC0142123

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142123
ProdDB ID	628874…9b5de9
LocalDB ID	660d7c38ec873d0035450df4
Component Type	fe_chip
Parents	20UPGM23210791 20UPGB43200170
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d7c38ec873d0035450df4
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	GiordonStark
ObjectId of this record	68dc739795403e048c93e167
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-10-01T00:02:42.000+00:00
MEASUREMENT_DURATION	757
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	119.616
TUNING_TUNED_NOISE_95_LOW	77.387
TUNING_TUNED_NOISE_MEAN	97.567
TUNING_TUNED_NOISE_SIGMA	11.085
TUNING_TUNED_TDAC_MEAN	-1.1
TUNING_TUNED_TDAC_SIGMA	4.795
TUNING_TUNED_THRESHOLD_95_HIGH	1567.69
TUNING_TUNED_THRESHOLD_95_LOW	1434.519
TUNING_TUNED_THRESHOLD_FAILED_FITS	4
TUNING_TUNED_THRESHOLD_MEAN	1503.9
TUNING_TUNED_THRESHOLD_SIGMA	38
TUNING_TUNED_TOT_95_HIGH	11.24
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	119.841
TUNING_UNTUNED_NOISE_95_LOW	77.34
TUNING_UNTUNED_NOISE_MEAN	97.442
TUNING_UNTUNED_NOISE_SIGMA	11.677
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3367.207
TUNING_UNTUNED_THRESHOLD_95_LOW	1800.74
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	274
TUNING_UNTUNED_THRESHOLD_MEAN	2523.426
TUNING_UNTUNED_THRESHOLD_SIGMA	399

Attachments

Filename	Contents
0x22b2b_L2_cold.json	Download
0x22b2b.log	Download
output.log	Download
20UPGFC0142123_MODULE__FINAL_COLD_TUNING.zip	Download

ProductionDB Record

Expand ProductionDB Record
