20UPGFC0142123

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142123
ProdDB ID	628874…9b5de9
LocalDB ID	660d7c38ec873d0035450df4
Component Type	fe_chip
Parents	20UPGM23210791 20UPGB43200170
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d7c38ec873d0035450df4
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	GiordonStark
ObjectId of this record	68d727d595403e048c93d666
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-26T23:38:04.000+00:00
MEASUREMENT_DURATION	753
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	130.618
TUNING_TUNED_NOISE_95_LOW	87.752
TUNING_TUNED_NOISE_MEAN	108.59
TUNING_TUNED_NOISE_SIGMA	11.321
TUNING_TUNED_TDAC_MEAN	-1.7
TUNING_TUNED_TDAC_SIGMA	4.147
TUNING_TUNED_THRESHOLD_95_HIGH	1562.323
TUNING_TUNED_THRESHOLD_95_LOW	1429.992
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_TUNED_THRESHOLD_MEAN	1498.1
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TOT_95_HIGH	9.94
TUNING_TUNED_TOT_95_LOW	5.03
TUNING_TUNED_TOT_MEAN	7.2
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	129.886
TUNING_UNTUNED_NOISE_95_LOW	87.746
TUNING_UNTUNED_NOISE_MEAN	108.16
TUNING_UNTUNED_NOISE_SIGMA	11.208
TUNING_UNTUNED_TDAC_MEAN	-1.308
TUNING_UNTUNED_TDAC_SIGMA	4.222
TUNING_UNTUNED_THRESHOLD_95_HIGH	1562.432
TUNING_UNTUNED_THRESHOLD_95_LOW	1430.55
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	3
TUNING_UNTUNED_THRESHOLD_MEAN	1498.891
TUNING_UNTUNED_THRESHOLD_SIGMA	35

Attachments

Filename	Contents
0x22b2b_L2_warm.json	Download
output.log	Download
0x22b2b.log	Download
20UPGFC0142123_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
