20UPGFC0141766

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141766
ProdDB ID	b44e17…4996fe
LocalDB ID	660d236aeeb7490035a471e4
Component Type	fe_chip
Parents	20UPGM24210028 20UPGB43200226
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d236aeeb7490035a471e4
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a03e52f5857bb4fa13d5b15
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2115.634
TUNING_UNTUNED_THRESHOLD_95_LOW	1529.657
TUNING_UNTUNED_THRESHOLD_95_HIGH	2753.065
TUNING_UNTUNED_THRESHOLD_SIGMA	311.172
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	99.344
TUNING_UNTUNED_NOISE_SIGMA	10.646
TUNING_UNTUNED_NOISE_95_LOW	80.111
TUNING_UNTUNED_NOISE_95_HIGH	119.87
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	94
TUNING_TUNED_THRESHOLD_MEAN	1497.0
TUNING_TUNED_THRESHOLD_95_LOW	1428.226
TUNING_TUNED_THRESHOLD_95_HIGH	1561.203
TUNING_TUNED_THRESHOLD_SIGMA	35.0
TUNING_TUNED_TDAC_MEAN	-1.0
TUNING_TUNED_TDAC_SIGMA	4.134
TUNING_TUNED_NOISE_MEAN	100.99
TUNING_TUNED_NOISE_SIGMA	10.915
TUNING_TUNED_NOISE_95_LOW	81.091
TUNING_TUNED_NOISE_95_HIGH	122.271
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.35
TUNING_TUNED_TOT_95_HIGH	10.07
TUNING_TUNED_THRESHOLD_FAILED_FITS	6
TUNING_ANY_ERRORS	{'tune_globalthreshold': 6, 'thresholdscan_hr': 83, 'tune_pixelthreshold': 8, 'thresholdscan_hd': 13, 'totscan': 0, 'all': 110}
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-13T07:19:31.000+00:00
MEASUREMENT_DURATION	662

Attachments

Filename	Contents
output.log	Download
0x229c6.log	Download
20UPGFC0141766_MODULE__FINAL_WARM_TUNING.zip	Download
