20UPGFC0141734

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141734
ProdDB ID	f24877…38900f
LocalDB ID	660d2344eeb7490035a471ac
Component Type	fe_chip
Parents	20UPGM24211150 20UPGB43200224
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	8
Target Iref trim version	1
Wafer serial number	None

Comments

Test: MIN_HEALTH_TEST QC Failed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	4 weeks ago
component ObjectId	660d2344eeb7490035a471ac
Stage	MODULE/FINAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	None
ObjectId of this record	6a0600eb8d85d0e79d6cd742
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
MIN_HEALTH_ANY_ERRORS	{'digitalscan': 0, 'analogscan': 12, 'thresholdscan_hr': 706, 'totscan': 7, 'all': 725}
MIN_HEALTH_THRESHOLD_MEAN	1486.53
MIN_HEALTH_THRESHOLD_SIGMA	56.19
MIN_HEALTH_NOISE_MEAN	89.9
MIN_HEALTH_NOISE_SIGMA	10.53
MIN_HEALTH_TOT_MEAN	6.62
MIN_HEALTH_TOT_SIGMA	2.65
MIN_HEALTH_COLUMN_DISABLED	15360
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	1
MIN_HEALTH_BAD_ANALOG	4
MIN_HEALTH_THRESHOLD_FAILED_FITS	1972
MIN_HEALTH_HIGH_ENC	0
MIN_HEALTH_BAD_ANALOG_INTEGRATED	15365
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	17335
MIN_HEALTH_HIGH_ENC_INDEPENDENT	0
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-14T09:07:11.000+00:00
MEASUREMENT_DURATION	390
