20UPGFC0141734

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141734
ProdDB ID	f24877…38900f
LocalDB ID	660d2344eeb7490035a471ac
Component Type	fe_chip
Parents	20UPGM24211150 20UPGB43200224
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	8
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d2344eeb7490035a471ac
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DavidJiang
ObjectId of this record	691b73ffd7bf966e0aaef945
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-10-31T21:31:09.000+00:00
MEASUREMENT_DURATION	695
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	120.153
TUNING_TUNED_NOISE_95_LOW	80.719
TUNING_TUNED_NOISE_MEAN	99.625
TUNING_TUNED_NOISE_SIGMA	11.326
TUNING_TUNED_TDAC_MEAN	-1.1
TUNING_TUNED_TDAC_SIGMA	4.028
TUNING_TUNED_THRESHOLD_95_HIGH	1560.846
TUNING_TUNED_THRESHOLD_95_LOW	1431.21
TUNING_TUNED_THRESHOLD_FAILED_FITS	1
TUNING_TUNED_THRESHOLD_MEAN	1498.2
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TOT_95_HIGH	10.22
TUNING_TUNED_TOT_95_LOW	5.35
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	117.098
TUNING_UNTUNED_NOISE_95_LOW	79.576
TUNING_UNTUNED_NOISE_MEAN	97.758
TUNING_UNTUNED_NOISE_SIGMA	10.431
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2666.459
TUNING_UNTUNED_THRESHOLD_95_LOW	1511.74
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	62
TUNING_UNTUNED_THRESHOLD_MEAN	2068.825
TUNING_UNTUNED_THRESHOLD_SIGMA	293.91

Attachments

Filename	Contents
0x229a6_L2_warm.json	Download
output.log	Download
0x229a6.log	Download
20UPGFC0141734_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
