Database for ITk Pixel Module

Serial Number	20UPGFC0141704
ProdDB ID	6c6e84…1f5592
LocalDB ID	660d23185d9bdc0035fd939b
Component Type	fe_chip
Parents	20UPGM24211149 20UPGB43200223
Children	No match.
Flags

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d23185d9bdc0035fd939b
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	691b6ec1d7bf966e0aaef6dc
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-10-30T21:42:24.000+00:00
MEASUREMENT_DURATION	682
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	123.147
TUNING_TUNED_NOISE_95_LOW	81.804
TUNING_TUNED_NOISE_MEAN	101.752
TUNING_TUNED_NOISE_SIGMA	10.927
TUNING_TUNED_TDAC_MEAN	-1
TUNING_TUNED_TDAC_SIGMA	3.817
TUNING_TUNED_THRESHOLD_95_HIGH	1562.659
TUNING_TUNED_THRESHOLD_95_LOW	1426.508
TUNING_TUNED_THRESHOLD_FAILED_FITS	6
TUNING_TUNED_THRESHOLD_MEAN	1497
TUNING_TUNED_THRESHOLD_SIGMA	36
TUNING_TUNED_TOT_95_HIGH	10.16
TUNING_TUNED_TOT_95_LOW	5.03
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	122.402
TUNING_UNTUNED_NOISE_95_LOW	81.811
TUNING_UNTUNED_NOISE_MEAN	101.339
TUNING_UNTUNED_NOISE_SIGMA	11.12
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2995.229
TUNING_UNTUNED_THRESHOLD_95_LOW	1736.632
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	81
TUNING_UNTUNED_THRESHOLD_MEAN	2331.722
TUNING_UNTUNED_THRESHOLD_SIGMA	319.225

Filename	Contents
0x22988_L2_warm.json	Download
output.log	Download
0x22988.log	Download
20UPGFC0141704_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
