20UPGFC0141607

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0141607
ProdDB ID	067389…190fc7
LocalDB ID	660d225feeb7490035a46f75
Component Type	fe_chip
Parents	20UPGM24210397 20UPGB43200228
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	4
Target Iref trim version	1
Wafer serial number	None

Comments

Date	Commented by	on which Component	Comment
a week ago	pixel (Lawrence Berkeley National Lab - pixel modules)	MODULE 20UPGM24210397	sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d225feeb7490035a46f75
Stage	MODULE/QC_CROSSCHECK
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	None
ObjectId of this record	6a074cf15857bb4fa13d61e6
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
MIN_HEALTH_ANY_ERRORS	{'digitalscan': 0, 'analogscan': 0, 'thresholdscan_hr': 0, 'totscan': 0, 'all': 0}
MIN_HEALTH_THRESHOLD_MEAN	2040.48
MIN_HEALTH_THRESHOLD_SIGMA	306.92
MIN_HEALTH_NOISE_MEAN	103.52
MIN_HEALTH_NOISE_SIGMA	10.71
MIN_HEALTH_TOT_MEAN	11.22
MIN_HEALTH_TOT_SIGMA	2.02
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	3
MIN_HEALTH_BAD_ANALOG	3
MIN_HEALTH_THRESHOLD_FAILED_FITS	148
MIN_HEALTH_HIGH_ENC	4
MIN_HEALTH_BAD_ANALOG_INTEGRATED	6
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	154
MIN_HEALTH_HIGH_ENC_INDEPENDENT	4
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-15T06:12:00.000+00:00
MEASUREMENT_DURATION	370

Attachments

Filename	Contents
output.log	Download
0x22927.log	Download
