20UPGFC0134710

MODULE/TAB_CUTTING

Component Information

Serial Number 20UPGFC0134710
ProdDB ID  0c3303…1ea690
LocalDB ID 65d9305a996084004284a9ac
Component Type fe_chip
Parents 20UPGM23211391  20UPGB43200036 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number None
Target Iref trim None
Target Iref trim version None

 Comments


Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 months ago
component ObjectId 65d9305a996084004284a9ac
Stage MODULE/POST_PARYLENE_WARM
Test Type PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name Simpson,Liana Rae
ObjectId of this record 68bb715efe566085fbd74fb3
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
PIXEL_FAILURE_SOURCE_SCAN_DONE False
PIXEL_FAILURE_COLUMN_DISABLED 0
PIXEL_FAILURE_DEAD_DIGITAL 0
PIXEL_FAILURE_BAD_DIGITAL 0
PIXEL_FAILURE_DEAD_ANALOG 2
PIXEL_FAILURE_BAD_ANALOG 4
PIXEL_FAILURE_TUNING_BAD 21
PIXEL_FAILURE_HIGH_ENC 0
PIXEL_FAILURE_HIGH_NOISE 3
PIXEL_FAILURE_MERGED_BUMPS 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN 1
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN -1
PIXEL_FAILURE_ELECTRICALLY_FAILED 30
PIXEL_FAILURE_DISCONNECTED_PIXELS 1
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC 3
PIXEL_FAILURE_FAILING_PIXELS 31
ANALYSIS_VERSION mqat v2.6.4
YARR_VERSION v1.5.2
MEASUREMENT_DATE 2025-03-07T18:35:09.000+00:00
MEASUREMENT_DURATION 698
