20UPGFC0134692

MODULE/TAB_CUTTING

Component Information

Serial Number	20UPGFC0134692
ProdDB ID	d3de9a…f081ba
LocalDB ID	65d9303e996084004284a985
Component Type	fe_chip
Parents	20UPGM23211391 20UPGB43200036
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: DATA_TRANSMISSION QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	9 months ago
component ObjectId	65d9303e996084004284a985
Stage	MODULE/POST_PARYLENE_WARM
Test Type	DATA_TRANSMISSION
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	67e6c2f2af9c029c40bf5b55
ObjectId of RAW record	67d1f550a7228273821eda6d
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.3.1rc3
MEASUREMENT_DATE	2025-03-07T17:33:48.000+00:00
MEASUREMENT_DURATION	10
MEASUREMENT_VERSION	2.3.0
YARR_VERSION	v1.5.2
EYE_WIDTH0	8

Attachments

Filename	Contents
output.log	Download

RAW Results Record
