20UPGFC0133432

MODULE/TAB_CUTTING

Component Information

Serial Number	20UPGFC0133432
ProdDB ID	52fd56…59a986
LocalDB ID	65d8de9899608400427c3e30
Component Type	fe_chip
Parents	20UPGM23211208 20UPGB43200031
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: SLDO QC Passed

(Stage: MODULE/RECEPTION)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	6 months ago
component ObjectId	65d8de9899608400427c3e30
Stage	MODULE/RECEPTION
Test Type	SLDO
Institute ObjectId
User Name	stefaniaSpagnolo
ObjectId of this record	6846f7fd3e9b42466e66a46c
ObjectId of RAW record	6846f7f93e9b42466e66a461
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.4.1
MEASUREMENT_DATE	2025-06-09T13:37:40.000+00:00
MEASUREMENT_DURATION	1506
MEASUREMENT_VERSION	2.4.1
YARR_VERSION	v1.5.4
SLDO_ANALOG_OVERHEAD	0.068
SLDO_D_MIN_IIN	5.125
SLDO_A_MIN_IIN	5.74
SLDO_D_SLOPE	0.135
SLDO_A_SLOPE	0.099
SLDO_D_OFFSET	-0.567
SLDO_A_OFFSET	-0.564
SLDO_A_CHI2	0
SLDO_DIGITAL_OVERHEAD	0.397
SLDO_D_CHI2	0
SLDO_IINA	0.611
SLDO_IIND	0.884
SLDO_IREF	3.8666163
SLDO_ISHUNTA	0.039
SLDO_ISHUNTD	0.251
SLDO_LINEARITY	0.024
SLDO_NOM_INPUT_CURRENT	6.06
SLDO_VDDA	1.21
SLDO_VDDD	1.2
SLDO_VINA	1.474
SLDO_VINA_VIND	-0.01
SLDO_VIND	1.48
SLDO_VI_OFFSET	0.938
SLDO_VI_SLOPE	0.089
SLDO_VOFFS	0.969

Attachments

Filename	Contents
output.log	Download

RAW Results Record
