20UPGFC0133432

MODULE/TAB_CUTTING

Component Information

Serial Number	20UPGFC0133432
ProdDB ID	52fd56…59a986
LocalDB ID	65d8de9899608400427c3e30
Component Type	fe_chip
Parents	20UPGM23211208 20UPGB43200031
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	9 months ago
component ObjectId	65d8de9899608400427c3e30
Stage	MODULE/POST_PARYLENE_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	AnnaRaquel Petri
ObjectId of this record	67b6fe6c85f06bd71a75d2d1
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.3.1rc2
MEASUREMENT_DATE	2025-02-19T16:02:02.000+00:00
MEASUREMENT_DURATION	1217
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-191-g1f95869
PIXEL_FAILURE_BAD_ANALOG	0
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	1
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	2
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	2
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	3
PIXEL_FAILURE_ELECTRICALLY_FAILED	82
PIXEL_FAILURE_FAILING_PIXELS	84
PIXEL_FAILURE_HIGH_ENC	1
PIXEL_FAILURE_HIGH_NOISE	0
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	True
PIXEL_FAILURE_TUNING_BAD	80

Attachments

Filename	Contents
output.log	Download
0x20938.log	Download
20UPGFC0133432_MODULE__POST_PARYLENE_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download
