20UPGM22110449

MODULE/COMPLETE

View QC Summary

Component Information

Serial Number 20UPGM22110449
ProdDB ID  d784cd…29a6f1
LocalDB ID 6553ec757c0b300042faf49d
Component Type MODULE
Parents No match.
Children 20UPGB42200047 Bare Module 20UPGFC0094502 FE Chip 20UPGPQ2110449 PCB 20UPGFC0094534 FE Chip 20UPGFC0094519 FE Chip 20UPGFC0094503 FE Chip
Flags • Other issues • Wirebond protection present
Distribution of chips on wafer

 Properties

Item Value
PCB-Bare Orientation isNormal True
FE chip version 2
Wirebond protection roof presence False
IREFTRIM_FE1 deleted None
IREFTRIM_FE2 deleted None
IREFTRIM_FE3 deleted None
IREFTRIM_FE4 deleted None
Alternative ID None
Rank None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/POST_PARYLENE_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a year ago
component ObjectId 6553ec757c0b300042faf49d
Stage MODULE/POST_PARYLENE_COLD
Test Type IV_MEASURE
Institute ObjectId
User Name Milou van Rijnbach
ObjectId of this record 669fc7899179d27ca4f5769b
ObjectId of RAW record 6686a296aee58d39438ed759
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.6
HUM 0
TEMP -28.82
BREAKDOWN_VOLTAGE 75
IV_ARRAY {'time': [2.4497432708740234, 9.360638856887817, 16.25739312171936, 23.072970628738403, 29.904402256011963, 36.62412738800049, 43.31163144111633, 50.014742612838745, 56.70173931121826, 63.470425605773926, 70.1258192062378, 76.7815809249878, 83.43674159049988, 90.1885724067688, 96.89164400100708, 103.54802012443542, 110.20273900032043, 116.92322301864624, 123.64267039299011, 130.41026329994202, 137.1459391117096, 143.8970205783844, 150.55274152755737, 157.20873308181763, 163.9122440814972, 170.64782190322876, 177.41506576538086, 184.1507375240326, 190.82251048088074, 197.510174036026, 204.18176007270813, 210.88534712791443, 217.63684558868408, 224.43564367294312, 231.33209586143494, 238.2435667514801, 245.1227526664734, 251.76269054412842, 258.44963932037354, 265.1860089302063, 271.8416361808777], 'voltage': [0, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 130, 135, 140, 145, 150, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0.0013492166666666668, 0.004170496666666667, 0.004604023333333334, 0.004949476666666667, 0.0052288633333333326, 0.005354103333333333, 0.006631303333333332, 0.0047801933333333334, 0.00719696, 0.005177940000000001, 0.008460393333333333, 0.006262456666666668, 0.004862773333333334, 0.005169683333333334, 0.004890296666666667, 0.006168873333333333, 0.005505496666666666, 0.005954166666666667, 0.006043626666666667, 0.0051641766666666675, 0.007707563333333333, 0.005833056666666667, 0.006474406666666667, 0.008259453333333335, 0.005667900000000001, 0.0073634899999999994, 0.008536083333333333, 0.007042810000000001, 0.007313936666666666, 0.005948660000000001, 0.00674278, 0.007604336666666668, 0.007779126666666667, 0.008478286666666666, 0.006627173333333332, 0.007885103333333332, 0.008377813333333333, 0.00791538, 0.006837743333333334, 0.007517633333333333, 0.005977563333333334], 'sigma current': [3.27394688750783e-05, 7.455062992505307e-05, 6.077496981122701e-05, 4.021850845347489e-05, 5.0719222084815985e-05, 0.00047250442130794453, 0.0001415910049716752, 0.0002856633305522819, 0.00018129450865005982, 0.0010372978912861373, 0.0002261743672970534, 0.0008189186769691414, 0.0006452435060932854, 0.0007265874304047806, 0.0005225394723420955, 0.00038450858597551386, 0.0008769845130648292, 0.0005975026332066568, 0.000977654297501025, 0.0005225509675513854, 0.0003766770508303128, 0.00014383638606262165, 0.0005222764843984033, 0.0007175708127812583, 0.00025639545328781996, 0.000632714362252035, 0.0008576026435101258, 0.0005230298164222256, 4.06443520744957e-05, 0.0007033143366944825, 0.0006886416238266943, 9.368972705454734e-05, 6.563139611158315e-05, 0.00023843450817549253, 0.00066105936926186, 0.00012081978986168688, 0.00042542705323265714, 0.00023704180939235203, 0.0004811259943322768, 0.0005532208471809027, 0.0002125787824679489], 'temperature': [-28.936147689819336, -28.58588218688965, -28.58588218688965, -28.67328453063965, -28.58588218688965, -28.23700523376465, -28.67328453063965, -28.67328453063965, -28.4112606048584, -28.67328453063965, -28.67328453063965, -28.67328453063965, -28.67328453063965, -28.760839462280273, -28.67328453063965, -28.760839462280273, -29.0239315032959, -28.760839462280273, -28.58588218688965, -28.498525619506836, -28.936147689819336, -28.848440170288086, -28.760839462280273, -29.111806869506836, -29.111806869506836, -28.936147689819336, -29.0239315032959, -29.111806869506836, -28.936147689819336, -28.58588218688965, -28.936147689819336, -28.936147689819336, -28.848440170288086, -28.848440170288086, -28.936147689819336, -28.936147689819336, -29.2878475189209, -29.0239315032959, -29.111806869506836, -29.0239315032959, -29.111806869506836], 'humidity': []}
LEAK_CURRENT 0
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED False

Attachments

Filename Contents
output.log Download

RAW Results Record

Download RAW
_id6686a296aee58d39438ed759
raw
serialNumbertestTypesubtestTyperesultsstagecomponentdbVersionaddresssys
20UPGM22110449IV_MEASURE
property
IV_MEASURE_MEASUREMENT_VERSION2.2.4
