20UPGM22110271

MODULE/LONG_TERM_STABILITY_TEST

Component Information

Serial Number	20UPGM22110271
ProdDB ID	9fb82e…cc85b8
LocalDB ID	64f5e0f6703d130042de00c4
Component Type	MODULE
Parents	No match.
Children	20UPGB42000018 Bare Module 20UPGPQ2110271 PCB 20UPGFC0086710 FE Chip 20UPGFC0086730 FE Chip 20UPGFC0086731 FE Chip 20UPGFC0086711 FE Chip
Flags

Distribution of chips on wafer

Properties

Item	Value
PCB-Bare Orientation isNormal	True
FE chip version	2
Wirebond protection roof presence	False
Alternative ID	None
Rank	None

Comments

Test: LONG_TERM_STABILITY_DCS QC Failed

(Stage: MODULE/LONG_TERM_STABILITY_TEST)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	64f5e0f6703d130042de00c4
Stage	MODULE/LONG_TERM_STABILITY_TEST
Test Type	LONG_TERM_STABILITY_DCS
Institute ObjectId
User Name	Milou van Rijnbach
ObjectId of this record	6718aaf3887d87226f27788a
ObjectId of RAW record	6718aaf1887d87226f277885
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.8
MEASUREMENT_DATE	None
MOD_HUM	None
TESTBOX_ID	None
BIAS_VOLT_AVE	20
BIAS_VOLT_STD	0
DURATION	28950
LEAKAGE_CURR_AVE	1.4937752e-07
LEAKAGE_CURR_MAX	1.51317e-07
LEAKAGE_CURR_MED	1.495995e-07
LEAKAGE_CURR_MIN	1.45851e-07
LEAKAGE_CURR_STD	1.16893e-09
LV_CURR_AVE	5.88
LV_CURR_MAX	5.88
LV_CURR_MED	5.88
LV_CURR_MIN	5.879
LV_CURR_STD	0
LV_VOLT_AVE	2.6728020833333335
LV_VOLT_MAX	2.676
LV_VOLT_MED	2.674
LV_VOLT_MIN	2.666
LV_VOLT_STD	0.002
MOD_TEMP_AVE	19.63
MOD_TEMP_MAX	19.864
MOD_TEMP_MED	19.642
MOD_TEMP_MIN	19.388
MOD_TEMP_STD	0.16

Attachments

Filename	Contents
output.log	Download

RAW Results Record
