Database for ITk Pixel Module

Serial Number	20UPGFC0097899
ProdDB ID	74581e…fea7a3
LocalDB ID	6232fc71a3cd8a000a66f783
Component Type	fe_chip
Parents	20UPIMS2102142 20UPGB12100055
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000382

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	6232fc71a3cd8a000a66f783
Stage	MODULE/INITIAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	JuanIgnacioCarlotto
ObjectId of this record	66696f94a2332dec72e60503
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.5rc1
MIN_HEALTH_BAD_ANALOG	1
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	28
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	4
MIN_HEALTH_HIGH_ENC_INDEPENDENT	4
MIN_HEALTH_NOISE_MEAN	57.31
MIN_HEALTH_NOISE_SIGMA	10.72
MIN_HEALTH_THRESHOLD_FAILED_FITS	2741
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	2770
MIN_HEALTH_THRESHOLD_MEAN	2568.87
MIN_HEALTH_THRESHOLD_SIGMA	437.38
MIN_HEALTH_TOT_MEAN	0
MIN_HEALTH_TOT_SIGMA	0.03
