Database for ITk Pixel Module

Serial Number	20UPGFC0097899
ProdDB ID	74581e…fea7a3
LocalDB ID	6232fc71a3cd8a000a66f783
Component Type	fe_chip
Parents	20UPIMS2102142 20UPGB12100055
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000382

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	6232fc71a3cd8a000a66f783
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	JuanIgnacioCarlotto
ObjectId of this record	66696c53a2332dec72e601ce
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.5rc1
TUNING_TUNED_NOISE_95_HIGH	74.265
TUNING_TUNED_NOISE_95_LOW	41.203
TUNING_TUNED_NOISE_MEAN	57.623
TUNING_TUNED_NOISE_SIGMA	8.565
TUNING_TUNED_TDAC_MEAN	1.5
TUNING_TUNED_TDAC_SIGMA	4.6
TUNING_TUNED_THRESHOLD_95_HIGH	1044.007
TUNING_TUNED_THRESHOLD_95_LOW	929.36
TUNING_TUNED_THRESHOLD_FAILED_FITS	173
TUNING_TUNED_THRESHOLD_MEAN	990.4
TUNING_TUNED_THRESHOLD_SIGMA	59
TUNING_TUNED_TOT_95_HIGH	7
TUNING_TUNED_TOT_95_LOW	7
TUNING_TUNED_TOT_MEAN	6.9
TUNING_TUNED_TOT_SIGMA	0.7
TUNING_UNTUNED_NOISE_95_HIGH	77.938
TUNING_UNTUNED_NOISE_95_LOW	43.738
TUNING_UNTUNED_NOISE_MEAN	60.419
TUNING_UNTUNED_NOISE_SIGMA	8.956
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2646.236
TUNING_UNTUNED_THRESHOLD_95_LOW	1404.645
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	50
TUNING_UNTUNED_THRESHOLD_MEAN	1984
TUNING_UNTUNED_THRESHOLD_SIGMA	315

Filename	Contents
0x17e6b_MODULE/INITIAL_WARM_L0_warm.json	Download
0x17e6b.log	Download
output.log	Download
20UPGFC0097899_MODULE__INITIAL_WARM_TUNING.zip	Download
