Database for ITk Pixel Module

Serial Number	20UPGFC0097899
ProdDB ID	74581e…fea7a3
LocalDB ID	6232fc71a3cd8a000a66f783
Component Type	fe_chip
Parents	20UPIMS2102142 20UPGB12100055
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000382

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	6232fc71a3cd8a000a66f783
Stage	MODULE/INITIAL_WARM
Test Type	SLDO
Institute ObjectId
User Name	JuanIgnacioCarlotto
ObjectId of this record	66696c14a2332dec72e5fff9
ObjectId of RAW record	664f35b9cd6d11892d76fb99
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.5rc1
SLDO_ANALOG_OVERHEAD	0.033
SLDO_DIGITAL_OVERHEAD	0.535
SLDO_IINA	0.797
SLDO_IIND	0.998
SLDO_IREF	4.1
SLDO_ISHUNTA	0.025
SLDO_ISHUNTD	0.348
SLDO_LINEARITY	0.002
SLDO_NOM_INPUT_CURRENT	5.55
SLDO_VDDA	1.2
SLDO_VDDD	1.2
SLDO_VINA	1.489
SLDO_VINA_VIND	-0.03
SLDO_VIND	1.508
SLDO_VI_OFFSET	1.177
SLDO_VI_SLOPE	0.062
SLDO_VOFFS	1.1

Filename	Contents
0x17e6b.log	Download
output.log	Download

_id

664f35b9cd6d11892d76fb99

raw

serialNumber

testType

subtestType

results

stage

component

dbVersion

address

sys

20UPGFC0097899

SLDO

property

SLDO_MEASUREMENT_VERSION	2.2.4.dev0

comment

Measurements

Temperature

X	False
Unit	C
Values	28.50164 29.53153 30.46258 31.00789 31.56335 32.12937 32.27257 32.41646 32.56105 32.41646 32.41646 32.27257 32.12937 31.84501 31.42352 31.28433 30.87063 30.46258 30.06001 29.66278 29.14118 28.50164

SetCurrent

X	False
Unit	A
Values	9.75 9.55 9.35 9.15 8.95 8.75 8.55 8.35 8.15 7.95 7.75 7.55 7.35 7.15 6.95 6.75 6.55 6.35 6.15 5.95 5.75 5.55

Current

X	True
Unit	A
Values	9.751 9.551 9.352 9.152 8.952 8.752 8.552 8.352 8.152 7.952 7.752 7.552 7.352 7.151 6.951 6.751 6.551 6.351 6.151 5.951 5.751 5.55

Vmux30

X	False
Unit	V
Values	0.192862 0.128726 0.126235 0.123708 0.121106 0.118476 0.11577 0.113056 0.11032 0.10758 0.104846 0.102069 0.0993138 0.0965171 0.0937257 0.0909544 0.0881708 0.0853789 0.0825859 0.0797859 0.0769836 0.0742064

Vmux33

X	False
Unit	V
Values	0.582083 0.576326 0.570269 0.564207 0.557946 0.551673 0.545246 0.538846 0.532293 0.525799 0.519393 0.512818 0.506329 0.499723 0.49312 0.486451 0.479901 0.473341 0.466493 0.459975 0.453235 0.446561

Vmux37

X	False
Unit	V
Values	0.589519 0.583541 0.577408 0.571165 0.564802 0.558356 0.551819 0.545266 0.538667 0.532075 0.525441 0.518794 0.512142 0.505454 0.49871 0.491858 0.485245 0.478412 0.471593 0.464818 0.457898 0.451116

Vmux34

X	False
Unit	V
Values	0.731073 0.728898 0.726052 0.723742 0.720872 0.718693 0.715337 0.712914 0.71029 0.706802 0.704824 0.702215 0.699385 0.69699 0.694306 0.691229 0.688248 0.686118 0.683442 0.681334 0.677989 0.67598

Vmux38

X	False
Unit	V
Values	0.733057 0.730419 0.728016 0.725212 0.722332 0.719426 0.716798 0.713518 0.710625 0.707651 0.704787 0.701985 0.698775 0.69652 0.693265 0.690196 0.686947 0.684624 0.681331 0.678752 0.675804 0.672549

Vmux36

X	False
Unit	V
Values	0.410476 0.408269 0.405754 0.403088 0.400304 0.397598 0.394791 0.391809 0.388931 0.385861 0.383144 0.379996 0.37713 0.374207 0.371039 0.368069 0.365001 0.362038 0.358956 0.356015 0.352998 0.350038

Vmux32

X	False
Unit	V
Values	0.731272 0.728728 0.726177 0.723739 0.720904 0.718252 0.715434 0.712729 0.709885 0.70708 0.704245 0.701428 0.698471 0.695489 0.692688 0.689763 0.686857 0.683921 0.68081 0.67792 0.674985 0.672011

Imux0

X	False
Unit	V
Values	0.166743 0.164358 0.161916 0.159392 0.156845 0.154218 0.151583 0.148952 0.146252 0.143521 0.140882 0.13817 0.135477 0.132719 0.130041 0.127288 0.124575 0.121859 0.119139 0.116403 0.113712 0.111007

Imux28

X	False
Unit	V
Values	0.77542 0.775156 0.759734 0.744044 0.728207 0.712153 0.695969 0.679961 0.663609 0.647299 0.631103 0.614685 0.598206 0.581548 0.565138 0.548255 0.531689 0.514823 0.497781 0.480859 0.463872 0.446849

Imux29

X	False
Unit	V
Values	0.464535 0.344583 0.330618 0.316589 0.302016 0.287907 0.274345 0.260548 0.246635 0.233064 0.219208 0.205866 0.192551 0.179207 0.166209 0.153069 0.140302 0.127797 0.115144 0.103108 0.0912045 0.0799789

Imux30

X	False
Unit	V
Values	0.774888 0.781537 0.766422 0.77076 0.764959 0.758873 0.752383 0.745192 0.737508 0.729429 0.719685 0.709348 0.697108 0.683086 0.667718 0.650537 0.632255 0.6132 0.593812 0.574129 0.554187 0.533679

Imux31

X	False
Unit	V
Values	0.597755 0.519276 0.576019 0.49131 0.476436 0.461367 0.445742 0.429845 0.413737 0.397648 0.380925 0.364391 0.347756 0.330901 0.314435 0.298012 0.281466 0.265054 0.248657 0.232587 0.216492 0.200704

Imux63

X	False
Unit	V
Values	0.285627 0.124101 0.121605 0.119074 0.116488 0.113843 0.111178 0.108497 0.105805 0.103123 0.100387 0.0976532 0.0949214 0.0921868 0.0894752 0.0867173 0.0839802 0.0812345 0.0784876 0.0757411 0.0730119 0.0702819

Metadata

ChipID

Name

0x17e6b

Institution

IFAE

ModuleSN

20UPIMS2102142

TimeStart

1716398225

useCalibAdc

False

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

RD53B

GlobalConfig

AuroraActiveLanes	15
CdrClkSel	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
SerEnTap	1
SerInvTap	1
MonitorEnable	1
MonitorI	63
MonitorV	32
ServiceBlockEn	1
ServiceBlockPeriod	50
DiffPreComp	350
DiffPreampL	900
DiffPreampM	900
DiffPreampR	900
DiffPreampT	900
DiffPreampTL	900
DiffPreampTR	900
DiffVff	150
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
SerEnLane	15
SldoTrimA	4
SldoTrimD	4

Parameter

ADCcalPar	5.0 0.186 10000.0
Name	0x17e6b
ChipId	1
InjCap	7.507
NfDSLDO	1.2830708111742812
NfASLDO	1.2816934330013277
NfACB	1.2795699749846907
VcalPar	2.743 0.2
IrefTrim	9
KSenseInA	21155.177
KSenseInD	21537.78
KSenseShuntA	26192.123904761906
KSenseShuntD	26665.822857142855
KShuntA	1056.327
KShuntD	1054.193

SoftwareType

TimeEnd

1716399127

AverageTemperature

31.04240818181818

MODULE/INITIAL_WARM

6232fc71a3cd8a000a66f783

1.01

64657cef8d79bac1f3f00596

mts	2024-05-23 12:25:29.038000
cts	2024-05-23 12:25:29.038000
rev	0

rawHash

8490bb6b60e53e07fa39e7f712e5c240

stage

MODULE/INITIAL_WARM
