Database for ITk Pixel Module

Serial Number	20UPGFC0099675
ProdDB ID	0de4d0…ec4cc8
LocalDB ID	622cea1bbe7827000a0db371
Component Type	fe_chip
Parents	20UPGM22601067 20UPGB42307034
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000389
Target Iref trim	None
Target Iref trim version	None

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622cea1bbe7827000a0db371
Stage	MODULE/THERMAL_CYCLES
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	Shift-LeaderHayashi-REPIC-KEK
ObjectId of this record	6719ad6ec447bfb7e214b570
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.6
MEASUREMENT_DATE	None
YARR_VERSION	None
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	1
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	2
MIN_HEALTH_HIGH_ENC_INDEPENDENT	2
MIN_HEALTH_NOISE_MEAN	102.39
MIN_HEALTH_NOISE_SIGMA	10.61
MIN_HEALTH_THRESHOLD_FAILED_FITS	25
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	26
MIN_HEALTH_THRESHOLD_MEAN	1476.91
MIN_HEALTH_THRESHOLD_SIGMA	45.21
MIN_HEALTH_TOT_MEAN	7
MIN_HEALTH_TOT_SIGMA	0.04

Filename	Contents
output.log	Download
0x1855b.log	Download
20UPGFC0099675_MODULE__THERMAL_CYCLES_MIN-HEALTH-TEST.zip	Download

Expand ProductionDB Record
