20UPGFC0099668

MODULE/COMPLETE

Component Information

Serial Number	20UPGFC0099668
ProdDB ID	afad07…8a2b06
LocalDB ID	622ce9e7be7827000a0db31d
Component Type	fe_chip
Parents	20UPGM22601067 20UPGB42307034
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	20UPGFW0000389
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Failed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	622ce9e7be7827000a0db31d
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	Shift-LeaderHayashi-REPIC-KEK
ObjectId of this record	671ef5d1c447bfb7e214f668
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.6
MEASUREMENT_DATE	None
YARR_VERSION	None
TUNING_TUNED_NOISE_95_HIGH	116.409
TUNING_TUNED_NOISE_95_LOW	74.963
TUNING_TUNED_NOISE_MEAN	94.85
TUNING_TUNED_NOISE_SIGMA	11.169
TUNING_TUNED_TDAC_MEAN	-0.8
TUNING_TUNED_TDAC_SIGMA	4.2
TUNING_TUNED_THRESHOLD_95_HIGH	1562.092
TUNING_TUNED_THRESHOLD_95_LOW	1427.849
TUNING_TUNED_THRESHOLD_FAILED_FITS	28
TUNING_TUNED_THRESHOLD_MEAN	1497.7
TUNING_TUNED_THRESHOLD_SIGMA	38
TUNING_TUNED_TOT_95_HIGH	7
TUNING_TUNED_TOT_95_LOW	7
TUNING_TUNED_TOT_MEAN	7
TUNING_TUNED_TOT_SIGMA	0.1
TUNING_UNTUNED_NOISE_95_HIGH	123.438
TUNING_UNTUNED_NOISE_95_LOW	78.794
TUNING_UNTUNED_NOISE_MEAN	99.763
TUNING_UNTUNED_NOISE_SIGMA	12.354
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3503.394
TUNING_UNTUNED_THRESHOLD_95_LOW	1911.088
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	167
TUNING_UNTUNED_THRESHOLD_MEAN	2640
TUNING_UNTUNED_THRESHOLD_SIGMA	404

Attachments

Filename	Contents
0x18554_L2_cold.json	Download
output.log	Download
0x18554.log	Download
20UPGFC0099668_MODULE__FINAL_COLD_TUNING.zip	Download
