Database for ITk Pixel Module

Serial Number	20UPGFC0096201
ProdDB ID	6c5316…227a3d
LocalDB ID	622cdf17be7827000a0d88dc
Component Type	fe_chip
Parents	20UPIMS2102148 20UPGB12200068
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000375

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622cdf17be7827000a0d88dc
Stage	MODULE/INITIAL_WARM
Test Type	DATA_TRANSMISSION
Institute ObjectId
User Name	JuanIgnacioCarlotto
ObjectId of this record	668bbfa2f5a4f84d8b2b9517
ObjectId of RAW record	668bbfa0f5a4f84d8b2b950e
Tags	No tags
