Database for ITk Pixel Module

Serial Number	20UPGFC0096069
ProdDB ID	1f5bb2…c7269e
LocalDB ID	622cdbfabe7827000a0d842c
Component Type	fe_chip
Parents	20UPIMS2102148 20UPGB12200053
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000375

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622cdbfabe7827000a0d842c
Stage	MODULE/FINAL_WARM
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	NirajKakoty
ObjectId of this record	669fc5db9c8630de5755f990
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.6
MIN_HEALTH_BAD_ANALOG	9
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	21
MIN_HEALTH_DEAD_DIGITAL	80
MIN_HEALTH_HIGH_ENC	3
MIN_HEALTH_HIGH_ENC_INDEPENDENT	3
MIN_HEALTH_NOISE_MEAN	67.46
MIN_HEALTH_NOISE_SIGMA	9.43
MIN_HEALTH_THRESHOLD_FAILED_FITS	41
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	148
MIN_HEALTH_THRESHOLD_MEAN	986.98
MIN_HEALTH_THRESHOLD_SIGMA	35.4
MIN_HEALTH_TOT_MEAN	7
MIN_HEALTH_TOT_SIGMA	0.17

Filename	Contents
output.log	Download
0x17745.log	Download
20UPGFC0096069_MODULE__FINAL_WARM_MIN-HEALTH-TEST.zip	Download

Expand ProductionDB Record

669fc62304ba2700427b5c2a

state

ready

stateTs

2024-07-23T15:02:59.704Z

stateUserIdentity

8194-5792-1

date

2024-07-23T15:01:00.000Z

testType

id	6393a08a15838700361eec84
code	MIN_HEALTH_TEST
name	Minimal Health Test
state	active

institution

id	5ecf13a093e5ee000a0e5ac6
code	IFAE
name	Institut de Fisica d'Altes Energies (IFAE)

user

id	6555f8e41525bb004261120c
userIdentity	8194-5792-1
firstName	Niraj
middleName
lastName	Kakoty

runNumber

669fc5db9c8630de5755f990

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Min Health Test Analysis Version	string	None	True	2.2.6	None	None

results

code	name	dataType	valueType	arrayDimensions	additional	rangeMin	rangeMax	value	associateChild
MIN_HEALTH_BAD_ANALOG	Number of bad pixels from analog scan	integer	single	None	None	None	None	9	None
MIN_HEALTH_BAD_DIGITAL	Number of bad pixels from digital scan	integer	single	None	None	None	None	0	None
MIN_HEALTH_DEAD_ANALOG	Number of dead pixels from analog scan	integer	single	None	None	None	None	21	None
MIN_HEALTH_DEAD_DIGITAL	Number of dead pixels from digital scan	integer	single	None	None	None	None	80	None
MIN_HEALTH_HIGH_ENC	Number of pixels with High ENC	integer	single	None	None	None	None	3	None
MIN_HEALTH_HIGH_ENC_INDEPENDENT	Number of pixels with High ENC	integer	single	None	None	None	None	3	None
MIN_HEALTH_NOISE_MEAN	Noise mean	float	single	None	None	None	None	67.46	None
MIN_HEALTH_NOISE_SIGMA	Noise sigma	float	single	None	None	None	None	9.43	None
MIN_HEALTH_THRESHOLD_FAILED_FITS	Number of failed fits from threshold scan	integer	single	None	None	None	None	41	None
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	Number of failed fits from threshold scan	integer	single	None	None	None	None	148	None
MIN_HEALTH_THRESHOLD_MEAN	Mean of threshold distribution	float	single	None	None	None	None	986.98	None
MIN_HEALTH_THRESHOLD_SIGMA	Sigma of threshold distribution	float	single	None	None	None	None	35.4	None
MIN_HEALTH_TOT_MEAN	Mean of ToT distribution	float	single	None	None	None	None	7	None
MIN_HEALTH_TOT_SIGMA	Sigma of ToT distribution	float	single	None	None	None	None	0.17	None

cts

2024-07-23T15:02:59.704Z

sys

cts	2024-07-23T15:02:59.704Z
mts	2024-07-23T15:03:00.219Z
rev	1

defects

comments

None

attachments

code

dateTime

title

description

contentType

type

url

urlCernbox

filename

user

b48fc0a295a316f2a9acafb0f5db642c

2024-07-23T15:03:00.219Z

TestRun_669fc62304ba2700427b5c2a_Attachment_Pack.zip

/home/data/viewer/static/cache/thumbnail/TestRun_669fc62304ba2700427b5c2a_Attachment_Pack.zip

None

eos

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/b/4/8/b48fc0a295a316f2a9acafb0f5db642c?authz=zteos64:MDAwMDAyYmV4nO2QrUsEURTF2QUXNYlx00UELfPx5ntu0mIwWocR3-x7szvs7rzhzVuE_RPWYBMMNoPRP8BgUwwmQREMBosiWCzi17gYDEajNxwuP869HM70aX26Jmf2dreOG82JTHULNlcfFos1yza4KA2qevRbW1zmbSkGBcvKrsG40iq7UUjBNJYYieEYweo8MzlPvJBqpBWmGiGpqSUsJBp1ktQkfuj5Vrh2UYtWZAbLhQQSgGWj6yLxwTItN4ZBxpA4xAtINI4TQ_uL2KYfDYsYVMZ4rlAKoXTLtpzQcdAmgbsUIabVoEt0Qjw9DHRixpDTPsfxH2A5QpVWYVcmLtCiQOiIUuHvh0z0aZbjD9LmAk2X2FAOWLWBkrTFEUSe8A7tpTgLHw8bZ9sHo8f9q9frmyPZuR1NLUye3-dPJ5vrhztv783_sv-qbHh5vrtsfALvlODz

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/b/4/8/b48fc0a295a316f2a9acafb0f5db642c

b48fc0a295a316f2a9acafb0f5db642c

id	6555f8e41525bb004261120c
userIdentity	8194-5792-1
firstName	Niraj
middleName
lastName	Kakoty

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

622cdbfabe7827000a0d842c

1f5bb23fd20dfdc13cd0bae736c7269e

ready

2022-03-12T17:44:26.915Z

9198-3887-1

False

None

False

None

20UPGFC0096069

None

parent

component

651ed652f0937c0038e9aadd

code

4adf54191803cf6545fd38f32f7e9801

state

ready

stateTs

2023-10-05T15:29:22.312Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB12200053

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	SINGLE_BARE_MODULE
name	Single bare module

testedAtStage

code	MODULE/LONG_TERM_STABILITY_TEST
name	Long Term Stability Test

highestLevelParent

component

66729817ead3ed0035c9e5e3

code

635d485d4ed0a53e0760f98e93faff81

state

ready

stateTs

2024-06-19T08:34:31.450Z

stateUserIdentity

7595-2623-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPIMS2102148

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PI
name	Inner pixels

componentType

code	MODULE
name	Module

type

code	TRIPLET_L0_STAVE_MODULE
name	Triplet L0 stave module

testedAtStage

code	MODULE/LONG_TERM_STABILITY_TEST
name	Long Term Stability Test

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V11
name	ITkpix_V1.1

code	name	dataType	required	default	value
WAFERSN	Wafer serial number	string	False	False	20UPGFW0000375

code	MODULE/FINAL_WARM
name	Final Warm
order	19
initial	False
final	False

code	BONN
name	University of Bonn

Past QC Stages and Results

Final Cold (MODULE/FINAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	Registered	Registered
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	Registered	Registered
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Final Warm (MODULE/FINAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	Registered	Registered
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	Registered	Registered
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered
