20UPGFC0096069

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0096069
ProdDB ID	1f5bb2…c7269e
LocalDB ID	622cdbfabe7827000a0d842c
Component Type	fe_chip
Parents	20UPIMS2102148 20UPGB12200053
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	20UPGFW0000375

Comments

Test: UNDERSHUNT_PROTECTION QC Failed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	622cdbfabe7827000a0d842c
Stage	MODULE/FINAL_WARM
Test Type	UNDERSHUNT_PROTECTION
Institute ObjectId
User Name	NirajKakoty
ObjectId of this record	669fc5409c8630de5755f927
ObjectId of RAW record	669fc53c9c8630de5755f920
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.6
USP_IINA_DIFF	0.986
USP_IINA_NOM	1.2422
USP_IIND_DIFF	0.001
USP_IIND_NOM	1.2822
USP_ISHUNTA_DIFF	1.528
USP_ISHUNTA_NOM	1.5378
USP_ISHUNTD_DIFF	0.001
USP_ISHUNTD_NOM	1.5874
USP_VDDA_DIFF	0.195
USP_VDDA_NOM	1.2126
USP_VDDD_DIFF	0.208
USP_VDDD_NOM	0.9918
USP_VINA_DIFF	0.002
USP_VINA_NOM	1.4504
USP_VIND_DIFF	0.01
USP_VIND_NOM	1.455
USP_VREFA_DIFF	0.097
USP_VREFA_NOM	0.6004
USP_VREFD_DIFF	0.105
USP_VREFD_NOM	0.4848

Attachments

Filename	Contents
output.log	Download
0x17745.log	Download
