Database for ITk Pixel Module

Serial Number	20UPGFC0096473
ProdDB ID	1f5fa0…e7311e
LocalDB ID	622cbe79be7827000a0d2edb
Component Type	fe_chip
Parents	20UPIM02202117 20UPGB12200126
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000376

Key	Data
QC Passed	False
Date	9 months ago
component ObjectId	622cbe79be7827000a0d2edb
Stage	MODULE/INITIAL_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	SimonHuiberts
ObjectId of this record	67bf09a15c8b0d342a448b89
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.3.0
MEASUREMENT_DATE	2025-02-26T09:37:18.000+00:00
MEASUREMENT_DURATION	None
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-71-gce544977
PIXEL_FAILURE_BAD_ANALOG	346
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	26
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	269
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	269
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	295
PIXEL_FAILURE_ELECTRICALLY_FAILED	651
PIXEL_FAILURE_FAILING_PIXELS	920
PIXEL_FAILURE_HIGH_ENC	6
PIXEL_FAILURE_HIGH_NOISE	165
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	True
PIXEL_FAILURE_TUNING_BAD	108

Filename	Contents
output.log	Download
0x178d9.log	Download
20UPGFC0096473_MODULE__INITIAL_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download
