Database for ITk Pixel Module

Serial Number	20UPGFC0096426
ProdDB ID	68d4ca…44be64
LocalDB ID	622cbd96be7827000a0d2daf
Component Type	fe_chip
Parents	20UPIM02202116 20UPGB12200116
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000376

Key	Data
QC Passed	False
Date	11 months ago
component ObjectId	622cbd96be7827000a0d2daf
Stage	MODULE/INITIAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	SimenHellesund
ObjectId of this record	6792286cf34390fa40d8092d
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.9rc4
MEASUREMENT_DATE	2025-01-23T09:20:43.000+00:00
MEASUREMENT_DURATION	None
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-71-gce544977
TUNING_TUNED_NOISE_95_HIGH	87.007
TUNING_TUNED_NOISE_95_LOW	45.39
TUNING_TUNED_NOISE_MEAN	65.19
TUNING_TUNED_NOISE_SIGMA	10.971
TUNING_TUNED_TDAC_MEAN	-1.139
TUNING_TUNED_TDAC_SIGMA	4.629
TUNING_TUNED_THRESHOLD_95_HIGH	1063.856
TUNING_TUNED_THRESHOLD_95_LOW	927.243
TUNING_TUNED_THRESHOLD_FAILED_FITS	254
TUNING_TUNED_THRESHOLD_MEAN	997.8
TUNING_TUNED_THRESHOLD_SIGMA	37
TUNING_TUNED_TOT_95_HIGH	-999
TUNING_TUNED_TOT_95_LOW	-999
TUNING_TUNED_TOT_MEAN	-999
TUNING_TUNED_TOT_SIGMA	-999
TUNING_UNTUNED_NOISE_95_HIGH	106.468
TUNING_UNTUNED_NOISE_95_LOW	49.685
TUNING_UNTUNED_NOISE_MEAN	74.314
TUNING_UNTUNED_NOISE_SIGMA	15.104
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	4236.295
TUNING_UNTUNED_THRESHOLD_95_LOW	1993.709
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	5294
TUNING_UNTUNED_THRESHOLD_MEAN	2972
TUNING_UNTUNED_THRESHOLD_SIGMA	570

Filename	Contents
0x178aa_R0_cold.json	Download
output.log	Download
0x178aa.log	Download
20UPGFC0096426_MODULE__INITIAL_COLD_TUNING.zip	Download

Expand ProductionDB Record

67922906f101812462624eef

state

ready

stateTs

2025-01-23T11:33:26.350Z

stateUserIdentity

5734-5343-1

date

2025-01-23T11:30:00.000Z

testType

id	6393a09015838700361eecc5
code	TUNING
name	Tuning
state	active

institution

id	5d318a25df98f20009738a14
code	UNIBERGEN
name	University of Bergen

user

id	633550eed0381d000a04e1ac
userIdentity	5734-5343-1
firstName	Simen
middleName
lastName	Hellesund

runNumber

6792286cf34390fa40d8092d

passed

False

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Tuning analysis version	string	None	True	2.2.9rc4	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-01-23T09:20:43.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	None	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	None	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.2-71-gce544977	None	None

results

code	name	dataType	valueType	arrayDimensions	additional	rangeMin	rangeMax	value	associateChild
TUNING_TUNED_NOISE_95_HIGH	Tuned noise 95% high	float	single	None	None	None	None	87.007	None
TUNING_TUNED_NOISE_95_LOW	Tuned noise 95% low	float	single	None	None	None	None	45.39	None
TUNING_TUNED_NOISE_MEAN	Tuned noise mean	float	single	None	None	None	None	65.19	None
TUNING_TUNED_NOISE_SIGMA	Tuned noise sigma	float	single	None	None	None	None	10.971	None
TUNING_TUNED_TDAC_MEAN	Tuned TDAC mean	float	single	None	None	None	None	-1.139	None
TUNING_TUNED_TDAC_SIGMA	Tuned TDAC sigma	float	single	None	None	None	None	4.629	None
TUNING_TUNED_THRESHOLD_95_HIGH	Tuned threshold 95% high	float	single	None	None	None	None	1063.856	None
TUNING_TUNED_THRESHOLD_95_LOW	Tuned threshold 95% low	float	single	None	None	None	None	927.243	None
TUNING_TUNED_THRESHOLD_FAILED_FITS	Number of failed fits from the tuned threshold scan	integer	single	None	None	None	None	254	None
TUNING_TUNED_THRESHOLD_MEAN	Mean of the tuned threshold distribution	float	single	None	None	None	None	997.8	None
TUNING_TUNED_THRESHOLD_SIGMA	Sigma of the tuned threshold distribution	float	single	None	None	None	None	37	None
TUNING_TUNED_TOT_95_HIGH	Tuned ToT 95% high	float	single	None	None	None	None	-999	None
TUNING_TUNED_TOT_95_LOW	Tuned ToT 95% low	float	single	None	None	None	None	-999	None
TUNING_TUNED_TOT_MEAN	Mean of tuned ToT distribution	float	single	None	None	None	None	-999	None
TUNING_TUNED_TOT_SIGMA	Sigma of tuned ToT distribution	float	single	None	None	None	None	-999	None
TUNING_UNTUNED_NOISE_95_HIGH	Untuned noise 95% high	float	single	None	None	None	None	106.468	None
TUNING_UNTUNED_NOISE_95_LOW	Noise 95% low	float	single	None	None	None	None	49.685	None
TUNING_UNTUNED_NOISE_MEAN	Untuned noise mean	float	single	None	None	None	None	74.314	None
TUNING_UNTUNED_NOISE_SIGMA	Untuned noise sigma	float	single	None	None	None	None	15.104	None
TUNING_UNTUNED_TDAC_MEAN	Untuned TDAC mean	float	single	None	None	None	None	0	None
TUNING_UNTUNED_TDAC_SIGMA	Untuned TDAC sigma	float	single	None	None	None	None	0	None
TUNING_UNTUNED_THRESHOLD_95_HIGH	Untuned threshold 95% high	float	single	None	None	None	None	4236.295	None
TUNING_UNTUNED_THRESHOLD_95_LOW	Untuned threshold 95% low	float	single	None	None	None	None	1993.709	None
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	Number of failed fits from the untuned threshold scan	integer	single	None	None	None	None	5294	None
TUNING_UNTUNED_THRESHOLD_MEAN	Mean of the untuned threshold distribution	float	single	None	None	None	None	2972	None
TUNING_UNTUNED_THRESHOLD_SIGMA	Sigma of the untuned threshold distribution	float	single	None	None	None	None	570	None
