Database for ITk Pixel Module

Serial Number	20UPGFC0096395
ProdDB ID	de4100…293c8e
LocalDB ID	622cbcd2be7827000a0d2c8e
Component Type	fe_chip
Parents	20UPIM02202117 20UPGB12200128
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000376

Key	Data
QC Passed	False
Date	9 months ago
component ObjectId	622cbcd2be7827000a0d2c8e
Stage	MODULE/INITIAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	SimonHuiberts
ObjectId of this record	67c028adc9eb389b9c4af7d8
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.3.0
MEASUREMENT_DATE	2025-02-26T12:54:39.000+00:00
MEASUREMENT_DURATION	None
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-71-gce544977
MIN_HEALTH_BAD_ANALOG	1
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_ANALOG	26
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	33
MIN_HEALTH_HIGH_ENC_INDEPENDENT	33
MIN_HEALTH_NOISE_MEAN	77.6
MIN_HEALTH_NOISE_SIGMA	14.57
MIN_HEALTH_THRESHOLD_FAILED_FITS	9106
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	9133
MIN_HEALTH_THRESHOLD_MEAN	3121.39
MIN_HEALTH_THRESHOLD_SIGMA	548.04
MIN_HEALTH_TOT_MEAN	-999
MIN_HEALTH_TOT_SIGMA	-999

Filename	Contents
output.log	Download
0x1788b.log	Download
20UPGFC0096395_MODULE__INITIAL_COLD_MIN-HEALTH-TEST.zip	Download

Expand ProductionDB Record
