Database for ITk Pixel Module

Serial Number	20UPGFC0096363
ProdDB ID	a6c849…4924f8
LocalDB ID	622cbbbfbe7827000a0d2b4b
Component Type	fe_chip
Parents	20UPIM02202117 20UPGB12200127
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000376

Key	Data
QC Passed	False
Date	9 months ago
component ObjectId	622cbbbfbe7827000a0d2b4b
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	SimonHuiberts
ObjectId of this record	67bf09935c8b0d342a448b04
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.3.0
MEASUREMENT_DATE	2025-02-26T09:26:00.000+00:00
MEASUREMENT_DURATION	None
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-71-gce544977
TUNING_TUNED_NOISE_95_HIGH	94.016
TUNING_TUNED_NOISE_95_LOW	54.886
TUNING_TUNED_NOISE_MEAN	73.898
TUNING_TUNED_NOISE_SIGMA	10.187
TUNING_TUNED_TDAC_MEAN	-1.182
TUNING_TUNED_TDAC_SIGMA	4.039
TUNING_TUNED_THRESHOLD_95_HIGH	1070.424
TUNING_TUNED_THRESHOLD_95_LOW	934.202
TUNING_TUNED_THRESHOLD_FAILED_FITS	225
TUNING_TUNED_THRESHOLD_MEAN	1004.4
TUNING_TUNED_THRESHOLD_SIGMA	36
TUNING_TUNED_TOT_95_HIGH	-999
TUNING_TUNED_TOT_95_LOW	-999
TUNING_TUNED_TOT_MEAN	-999
TUNING_TUNED_TOT_SIGMA	-999
TUNING_UNTUNED_NOISE_95_HIGH	101.522
TUNING_UNTUNED_NOISE_95_LOW	57.842
TUNING_UNTUNED_NOISE_MEAN	78.634
TUNING_UNTUNED_NOISE_SIGMA	11.852
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3808.104
TUNING_UNTUNED_THRESHOLD_95_LOW	1981.621
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	380
TUNING_UNTUNED_THRESHOLD_MEAN	2783
TUNING_UNTUNED_THRESHOLD_SIGMA	464

Filename	Contents
0x1786b_R0_warm.json	Download
output.log	Download
0x1786b.log	Download
20UPGFC0096363_MODULE__INITIAL_WARM_TUNING.zip	Download
