Database for ITk Pixel Module

Serial Number	20UPGFC0096323
ProdDB ID	8e24ad…2d3543
LocalDB ID	622cbae4be7827000a0d29cb
Component Type	fe_chip
Parents	20UPGM22110303 20UPGB42200012
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000376

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	622cbae4be7827000a0d29cb
Stage	MODULE/INITIAL_WARM
Test Type	SLDO
Institute ObjectId
User Name	FrancescoCrescioli
ObjectId of this record	659fc69d4248d8ac52f21404
ObjectId of RAW record	659fc6994248d8ac52f213f7
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.2
SLDO_ANALOG_OVERHEAD	0.076
SLDO_DIGITAL_OVERHEAD	0.381
SLDO_IINA	0.606
SLDO_IIND	0.866
SLDO_IREF	4
SLDO_ISHUNTA	0.043
SLDO_ISHUNTD	0.239
SLDO_LINEARITY	0.004
SLDO_NOM_INPUT_CURRENT	5.88
SLDO_VDDA	1.21
SLDO_VDDD	1.18
SLDO_VINA	1.49
SLDO_VINA_VIND	-0.01
SLDO_VIND	1.492
SLDO_VI_OFFSET	0.971
SLDO_VI_SLOPE	0.088
SLDO_VOFFS	0.99

Filename	Contents
output.log	Download
0x17843.log	Download

_id

659fc6994248d8ac52f213f7

raw

serialNumber

testType

subtestType

results

stage

component

dbVersion

address

sys

20UPGFC0096323

SLDO

property

SLDO_MEASUREMENT_VERSION	2.2.1.dev0

comment

Measurements

Temperature

X	False
Unit	C
Values	29.85 31.18 30.92 30.41 29.89 29.4 28.89 28.46 27.98 27.5 27.23 26.57 26.3 25.78 25.33 25.03 24.59 24.29 23.87

SetCurrent

X	False
Unit	A
Values	9.48 9.280000000000001 9.08 8.88 8.68 8.48 8.280000000000001 8.08 7.880000000000001 7.68 7.48 7.28 7.08 6.88 6.68 6.48 6.28 6.08 5.88

Current

X	True
Unit	A
Values	9.509499549865723 9.310999870300293 9.111000061035156 8.910499572753906 8.71049976348877 8.509499549865723 8.309000015258789 8.109000205993652 7.908999919891357 7.708499908447266 7.508500099182129 7.308000087738037 7.107500076293945 6.906499862670898 6.706500053405762 6.506499767303467 6.306000232696533 6.105999946594238 5.906000137329102

Vmux30

X	False
Unit	V
Values	0.118069039 0.116097527 0.111980192 0.109593941 0.107433092 0.104556968 0.101205999 0.0986183888 0.0959045542 0.0930224198 0.0931125804 0.0907924472 0.0855901796 0.0822362046 0.0797417609 0.0769077121 0.074843034 0.0720330281 0.0716273053

Vmux33

X	False
Unit	V
Values	0.569061464 0.562275375 0.555558409 0.548417688 0.540282195 0.534157283 0.526478604 0.520092227 0.512708072 0.505456153 0.500410164 0.490841117 0.483499038 0.476863216 0.469385896 0.463149786 0.456198403 0.448156076 0.444065789

Vmux37

X	False
Unit	V
Values	0.569845861 0.563375334 0.556460015 0.549024769 0.542494135 0.534674204 0.527984286 0.520939737 0.513765957 0.506838616 0.501858745 0.492076318 0.484779319 0.477773839 0.471020808 0.464150569 0.45625851 0.449562581 0.444744999

Vmux34

X	False
Unit	V
Values	0.727254278 0.725832745 0.722085069 0.718788196 0.715271932 0.712522033 0.709014785 0.705859163 0.703205436 0.700701976 0.699995718 0.694228443 0.691761048 0.688578378 0.685624115 0.681858407 0.679517236 0.676833455 0.676611059

Vmux38

X	False
Unit	V
Values	0.710466371 0.70782767 0.704765214 0.701588555 0.698051254 0.694901643 0.693050345 0.689170433 0.686354416 0.682838152 0.6828652 0.67759381 0.674420156 0.671766428 0.668547694 0.666362802 0.663129041 0.660033527 0.659288199

Vmux36

X	False
Unit	V
Values	0.368682497 0.36646154 0.363137619 0.35974758 0.357003692 0.35371884 0.35117631 0.348213031 0.344744853 0.342394666 0.341267658 0.33639598 0.333441717 0.330604663 0.327668432 0.324624008 0.322114538 0.319523923 0.318463033

Vmux32

X	False
Unit	V
Values	0.722319487 0.719602647 0.716798651 0.714364315 0.711118532 0.708572998 0.70600342 0.703557062 0.700392424 0.698435939 0.697651542 0.692614568 0.69020728 0.68778797 0.684004229 0.681464705 0.679667504 0.677527692 0.677191092

Imux0

X	False
Unit	V
Values	0.154328634 0.151473548 0.149673341 0.146785196 0.143617553 0.140714381 0.137928418 0.13556621 0.132882429 0.129859043 0.129970241 0.124320175 0.121395966 0.118796335 0.116292875 0.11421317 0.110555655 0.108049189 0.108806539

Imux28

X	False
Unit	V
Values	0.57127641 0.560565328 0.548598009 0.536176881 0.524738504 0.511866573 0.499391349 0.487231687 0.475417641 0.463002524 0.453253156 0.43893565 0.426292126 0.414493107 0.401972802 0.389656862 0.377142568 0.363861909 0.353661738

Imux29

X	False
Unit	V
Values	0.260339488 0.250334665 0.239888055 0.230090601 0.219544814 0.209846537 0.199057317 0.189127627 0.178813253 0.169433543 0.160757086 0.149024185 0.139244763 0.130078434 0.119610786 0.110531612 0.101061742 0.091444609 0.0848989482

Imux30

X	False
Unit	V
Values	0.730400883 0.719939246 0.709660936 0.69776274 0.684491097 0.670840779 0.656342952 0.641304161 0.626238322 0.61063753 0.596809896 0.578314948 0.562623996 0.546001383 0.529937766 0.513684812 0.497819549 0.481037653 0.466804297

Imux31

X	False
Unit	V
Values	0.403535586 0.389163984 0.375345366 0.36055602 0.347669062 0.332744475 0.318571226 0.304743592 0.290861863 0.276273875 0.265514708 0.248738822 0.234932226 0.221390102 0.208584289 0.194092472 0.181689376 0.167915839 0.157394095

Imux63

X	False
Unit	V
Values	0.115042648 0.111908064 0.110035728 0.10707846 0.103715469 0.101509539 0.0983418962 0.0959075596 0.0932418107 0.0903025745 0.0901763497 0.0844842094 0.0818665461 0.080243655 0.0768806639 0.0743441452 0.071735498 0.0687211281 0.0687000906

Metadata

ChipID

Name

0x17843

Institution

LPNHE

ModuleSN

20UPGM22110303

TimeStart

1704808442

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

RD53B

GlobalConfig

AuroraActiveLanes	1
CdrClkSel	1
CmlBias0	800
CmlBias1	400
CmlBias2	0
SerEnTap	1
SerInvTap	1
MonitorEnable	1
MonitorI	63
MonitorV	32
ServiceBlockEn	1
ServiceBlockPeriod	50
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffVff	60
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
SerEnLane	1
SldoTrimA	9
SldoTrimD	6

Parameter

ADCcalPar	10.269 0.194 10000.0
Name	0x17843
ChipId	13
InjCap	7.942
NfDSLDO	1.2873284043498447
NfASLDO	1.2860653889911497
NfACB	1.2843574477674602
VcalPar	7.336 0.21
IrefTrim	12
KSenseInA	21268.467
KSenseInD	21760.264
KSenseShuntA	26332.387714285713
KSenseShuntD	26941.279238095238
KShuntA	1051.899
KShuntD	1028.992

SoftwareType

TimeEnd

1704811844

AverageTemperature

27.551052631578948

MODULE/INITIAL_WARM

622cbae4be7827000a0d29cb

1.01

64657cef8d79bac1f3f00584

mts	2024-01-11 10:44:41.289000
cts	2024-01-11 10:44:41.289000
rev	0

rawHash

db440d57c3b9b97a59111b913174588b

stage

MODULE/INITIAL_WARM
