Database for ITk Pixel Module

Serial Number	20UPGFC0086214
ProdDB ID	2fcb61…1c4577
LocalDB ID	6225caf380e95c000a58d174
Component Type	fe_chip
Parents	20UPGM22110265 20UPGB42000083 20UPGM22110265 20UPGB42000083
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000336

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	6225caf380e95c000a58d174
Stage	MODULE/INITIAL_WARM
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	SimoneRavera
ObjectId of this record	662637fa02f983de45ca74d1
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.3rc4
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	0
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	0
MIN_HEALTH_HIGH_ENC_INDEPENDENT	0
MIN_HEALTH_NOISE_MEAN	113.61
MIN_HEALTH_NOISE_SIGMA	11.66
MIN_HEALTH_THRESHOLD_FAILED_FITS	251
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	251
MIN_HEALTH_THRESHOLD_MEAN	1963.82
MIN_HEALTH_THRESHOLD_SIGMA	321.18
MIN_HEALTH_TOT_MEAN	-999
MIN_HEALTH_TOT_SIGMA	-999
