Database for ITk Pixel Module

Serial Number	20UPGFC0084953
ProdDB ID	4b978a…d50d4f
LocalDB ID	6222073e80e95c000a45ebe3
Component Type	fe_chip
Parents	20UPGM22210906 20UPGB42000066
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000331

Key	Data
QC Passed	True
Date	12 months ago
component ObjectId	6222073e80e95c000a45ebe3
Stage	MODULE/FINAL_COLD
Test Type	INJECTION_CAPACITANCE
Institute ObjectId
User Name	Md ArifAbdullaSamy
ObjectId of this record	6762efb7888e9d75d4595249
ObjectId of RAW record	6762efb1888e9d75d459523c
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.9
MEASUREMENT_DATE	2024-12-18T15:49:37.000+00:00
YARR_VERSION	v1.5.2
INJ_CAPACITANCE	7.42

Filename	Contents
output.log	Download
0x14bd9.log	Download

_id

6762efb1888e9d75d459523c

raw

serialNumber

testType

subtestType

results

stage

component

dbVersion

address

sys

20UPGFC0084953

INJECTION_CAPACITANCE

property

YARR_VERSION	v1.5.2
INJECTION_CAPACITANCE_MEASUREMENT_VERSION	2.2.7

comment

Measurements

Vmux4

X	False
Unit	V
Values	0.613491237 0.613540411 0.613348246 0.613162875 0.613146484

Vmux30

X	False
Unit	V
Values	0.0136424769 0.0136424769 0.0136424769 0.0136424769 0.0136424769

Imux10

X	False
Unit	V
Values	0.107068129 0.107052416 0.107193172 0.107114002 0.107032754

Imux11

X	False
Unit	V
Values	0.0203739014 0.0203716625 0.020376306 0.0203692224 0.0203676187

Imux63

X	False
Unit	V
Values	0.0118330298 0.0118330298 0.0118330298 0.0118330298 0.0118330298

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

RD53B

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AutoRead0	137
AutoRead1	133
AutoRead2	121
AutoRead3	122
AutoRead4	124
AutoRead5	127
AutoRead6	126
AutoRead7	125
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrOverwriteLimit	0
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnEos	1
DataEnHitRemoval	0
DataEnIsoHitRemoval	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	100
DiffLccEn	0
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	319
DiffTh1M	254
DiffTh1R	319
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	55552
EfuseReadData1	4427
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	882
InjVcalMed	200
InjVcalRange	1
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	1
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixPortal	1445
PixRegionCol	199
PixRegionRow	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	1000
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	1
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	1
SerSelOut2	1
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	11
SldoTrimD	6
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	9.0 0.183 10000.0
ChipId	13
EnforceNameIdCheck	True
InjCap	7.42
IrefTrim	12
KSenseInA	20814.04
KSenseInD	21534.553
KSenseShuntA	25769.762
KSenseShuntD	26661.826
KShuntA	1077.166
KShuntD	1073.584
Name	0x14bd9
NfACB	1.2866832
NfASLDO	1.288601
NfDSLDO	1.2896458
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.19

SoftwareType

ChipID

Name

0x14bd9

Institution

ModuleSN

20UPGM22210906

TimeStart

1734536977

TimeEnd

1734537131

MODULE/FINAL_COLD

6222073e80e95c000a45ebe3

1.01

64657cef8d79bac1f3f00550

mts	2024-12-18 15:52:17.620000
cts	2024-12-18 15:52:17.620000
rev	0

rawHash

f7f24baa1b80be95b47afa54f5a1900c

stage

MODULE/FINAL_COLD
