Database for ITk Pixel Module

Serial Number	20UPGFC0084950
ProdDB ID	6073cb…dbf9e9
LocalDB ID	6222073b80e95c000a45ebda
Component Type	fe_chip
Parents	20UPGM22210906 20UPGB42000066
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000331

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	6222073b80e95c000a45ebda
Stage	MODULE/THERMAL_CYCLES
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	KennethWraight
ObjectId of this record	676197d7888e9d75d4592b82
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.9
MEASUREMENT_DATE	2024-12-16T16:05:08.000+00:00
YARR_VERSION	v1.5.2
PIXEL_FAILURE_BAD_ANALOG	1
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	0
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	442
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	1
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	0
PIXEL_FAILURE_DISCONNECTED_PIXELS	443
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	446
PIXEL_FAILURE_ELECTRICALLY_FAILED	528
PIXEL_FAILURE_FAILING_PIXELS	971
PIXEL_FAILURE_HIGH_ENC	1
PIXEL_FAILURE_HIGH_NOISE	0
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	True
PIXEL_FAILURE_TUNING_BAD	526

Filename	Contents
output.log	Download
0x14bd6.log	Download
20UPGFC0084950_MODULE__THERMAL_CYCLES_PIXEL-FAILURE-ANALYSIS.zip	Download

Expand ProductionDB Record

676199e221fb44dcfbb354eb

state

ready

stateTs

2024-12-17T15:33:54.904Z

stateUserIdentity

8281-1164-1

date

2024-12-17T15:25:00.000Z

testType

id	6393a09615838700361eed0a
code	PIXEL_FAILURE_ANALYSIS
name	Pixel Failure Analysis
state	active

institution

id	59d60ee4ed67730005160cd9
code	GL
name	Glasgow University

user

id	5e84a6cecefa85000a74fe54
userIdentity	8281-1164-1
firstName	Kenneth
middleName
lastName	Wraight

runNumber

676197d7888e9d75d4592b82

passed

False

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Pixel Failure Analysis Version	string	None	True	2.2.9	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2024-12-16T16:05:08.000+00:00	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.2	None	None

results

code	name	dataType	valueType	arrayDimensions	additional	rangeMin	rangeMax	value	associateChild
PIXEL_FAILURE_BAD_ANALOG	Number of bad pixels from analog scan	integer	single	None	None	None	None	1	None
PIXEL_FAILURE_BAD_DIGITAL	Number of bad pixels from digital scan	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_COLUMN_DISABLED	Number of disabled pixels due to core column issue	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_DEAD_ANALOG	Number of dead pixels from analog scan	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_DEAD_DIGITAL	Number of dead pixels from digital scan	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	Number of disconnected bump from source scan	integer	single	None	None	None	None	442	None
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	Number of bad (transition region) pixels from disconnected bump bond scan (xtalk based)	integer	single	None	None	None	None	1	None
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	Number of disconnected bumps from 0-bias threshold scan	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_DISCONNECTED_PIXELS	Number of disconnected pixels	integer	single	None	None	None	None	443	None
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	Number of pixels failing disconnected pixel test	integer	single	None	None	None	None	446	None
PIXEL_FAILURE_ELECTRICALLY_FAILED	Number of electrically failed pixels	integer	single	None	None	None	None	528	None
PIXEL_FAILURE_FAILING_PIXELS	Total number of failing pixels	integer	single	None	None	None	None	971	None
PIXEL_FAILURE_HIGH_ENC	Number of pixels with High ENC	integer	single	None	None	None	None	1	None
PIXEL_FAILURE_HIGH_NOISE	Number of pixels with high noise occupancy	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_MERGED_BUMPS	Number of merged bumps	integer	single	None	None	None	None	0	None
PIXEL_FAILURE_SOURCE_SCAN_DONE	Source scan done	boolean	single	None	None	None	None	True	None
PIXEL_FAILURE_TUNING_BAD	Number of pixels with bad tuning	integer	single	None	None	None	None	526	None

cts

2024-12-17T15:33:54.905Z

sys

cts	2024-12-17T15:33:54.905Z
mts	2024-12-17T15:33:59.216Z
rev	1

defects

comments

None

attachments

code

dateTime

title

description

contentType

type

url

urlCernbox

filename

user

e52ca2bff6ff0028fd03afb5d5b2fd90

2024-12-17T15:33:59.216Z

TestRun_676199e221fb44dcfbb354eb_Attachment_Pack.zip

/home/rd53a/localdb-tools/viewer/static/cache/thumbnail/TestRun_676199e221fb44dcfbb354eb_Attachment_Pack.zip

None

eos

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/5/2/e52ca2bff6ff0028fd03afb5d5b2fd90?authz=zteos64:MDAwMDAyYmV4nO2QvUrEQBSFSUCLrRax2moQF2ySyUwy-bkoiAsWlttYhICTnclu3N1MSCaNnQ9hYWGzjeA72O8DWPkCKtiKjaJxsbCwtPQWl8Ph3MvH6SzNjlF1357fb9d7a7melmLLPCt3DOpiqWrM9Yx_75GsinGlmlLk9RQLqa02jstKCUukWGKG6dE2CdyQO5RbmRcIixCZWVHocot7aeaQIPIDGg3vjPhYCnQoU0R9RAk4DFgrHMoS1OQCiEf8kMQrnASNvxzXCeKzMkE6F7LQUCmlbcL8MPI8cCNK92OArB1gxCbEt6PQJk6CCj6XsPqDRAGopdUwrVKGeFkCmqhaw--HQs15XsAPZyxVC0pcVDeiVUhXfCQBqSKVEz7LYAP1-wd7Hw073b0ePlx0b84Hjv3EzMHi5PLxHi-Mzd5_2X9VNlpevbyanxj22YM%3d

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/5/2/e52ca2bff6ff0028fd03afb5d5b2fd90

e52ca2bff6ff0028fd03afb5d5b2fd90

id	5e84a6cecefa85000a74fe54
userIdentity	8281-1164-1
firstName	Kenneth
middleName
lastName	Wraight

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

6222073b80e95c000a45ebda

6073cbd0e2a5d7416d6157221cdbf9e9

ready

2022-03-04T12:34:03.579Z

9198-3887-1

False

None

False

None

20UPGFC0084950

None

parent

component

63d148b89eb28800363f20ed

code

5f7632852f764a8528f722d588a758f4

state

ready

stateTs

2023-01-25T15:20:24.514Z

stateUserIdentity

4709-4605-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB42000066

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/POST_PARYLENE_COLD
name	Post-Parylene Cold

highestLevelParent

component

6671723c01875b0034ea8cbc

code

0176f303092bace75fbb36e03b14b533

state

ready

stateTs

2024-06-18T11:40:44.945Z

stateUserIdentity

24-7185-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM22210906

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/POST_PARYLENE_COLD
name	Post-Parylene Cold

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V11
name	ITkpix_V1.1

code	name	dataType	required	default	value
WAFERSN	Wafer serial number	string	False	False	20UPGFW0000331

code	MODULE/THERMAL_CYCLES
name	Thermal Cycles
order	17
initial	False
final	False

code	BONN
name	University of Bonn
