Database for ITk Pixel Module

Serial Number	20UPGFC0084827
ProdDB ID	1548ef…94337c
LocalDB ID	622206e280e95c000a45eadb
Component Type	fe_chip
Parents	20UPGM22110015 20UPGB42000042
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000331

Key	Data
QC Passed	False
Date	2 years ago
component ObjectId	622206e280e95c000a45eadb
Stage	MODULE/INITIAL_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	MatthiasSaimpert
ObjectId of this record	6554f0d58155ba5ba2d92ff7
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.0
PIXEL_FAILURE_BAD_ANALOG	8
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_DEAD_ANALOG	5
PIXEL_FAILURE_DEAD_DIGITAL	24576
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	-1
PIXEL_FAILURE_ELECTRICALLY_FAILED	76842
PIXEL_FAILURE_FAILING_PIXELS	-1
PIXEL_FAILURE_HIGH_ENC	0
PIXEL_FAILURE_HIGH_NOISE	1
PIXEL_FAILURE_MERGED_BUMPS	-1
PIXEL_FAILURE_SOURCE_SCAN_DONE	False
PIXEL_FAILURE_TUNING_BAD	52252

Filename	Contents
output.log	Download
0x14b5b.log	Download
20UPGFC0084827_MODULE__INITIAL_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download

Expand ProductionDB Record
