Database for ITk Pixel Module

Serial Number	20UPGFC0084805
ProdDB ID	a1ecdf…8cd855
LocalDB ID	622206cd80e95c000a45eaa5
Component Type	fe_chip
Parents	20UPGM22211262 20UPGB42000065
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000331

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622206cd80e95c000a45eaa5
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	KennethWraight
ObjectId of this record	675033fc710fb9a2fd3b6f86
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.9
MEASUREMENT_DATE	2024-12-03T14:24:00.000+00:00
YARR_VERSION	v1.5.2-94-g9bb8d771
TUNING_TUNED_NOISE_95_HIGH	56.01
TUNING_TUNED_NOISE_95_LOW	28.599
TUNING_TUNED_NOISE_MEAN	42.064
TUNING_TUNED_NOISE_SIGMA	9.032
TUNING_TUNED_TDAC_MEAN	1.461
TUNING_TUNED_TDAC_SIGMA	4.099
TUNING_TUNED_THRESHOLD_95_HIGH	1555.538
TUNING_TUNED_THRESHOLD_95_LOW	1421.19
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_TUNED_THRESHOLD_MEAN	1491.7
TUNING_TUNED_THRESHOLD_SIGMA	34
TUNING_TUNED_TOT_95_HIGH	8
TUNING_TUNED_TOT_95_LOW	8
TUNING_TUNED_TOT_MEAN	8
TUNING_TUNED_TOT_SIGMA	0
TUNING_UNTUNED_NOISE_95_HIGH	57.678
TUNING_UNTUNED_NOISE_95_LOW	28.964
TUNING_UNTUNED_NOISE_MEAN	42.869
TUNING_UNTUNED_NOISE_SIGMA	9.234
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2585.968
TUNING_UNTUNED_THRESHOLD_95_LOW	1506.146
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	5
TUNING_UNTUNED_THRESHOLD_MEAN	2005
TUNING_UNTUNED_THRESHOLD_SIGMA	275

Filename	Contents
0x14b45_L2_warm.json	Download
output.log	Download
0x14b45.log	Download
20UPGFC0084805_MODULE__FINAL_WARM_TUNING.zip	Download
