Database for ITk Pixel Module

Serial Number	20UPGFC0084805
ProdDB ID	a1ecdf…8cd855
LocalDB ID	622206cd80e95c000a45eaa5
Component Type	fe_chip
Parents	20UPGM22211262 20UPGB42000065
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000331

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622206cd80e95c000a45eaa5
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	Md ArifAbdullaSamy
ObjectId of this record	66a3682f892c62f686a8b90f
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.5rc1
TUNING_TUNED_NOISE_95_HIGH	54.544
TUNING_TUNED_NOISE_95_LOW	27.703
TUNING_TUNED_NOISE_MEAN	40.801
TUNING_TUNED_NOISE_SIGMA	8.795
TUNING_TUNED_TDAC_MEAN	1.3
TUNING_TUNED_TDAC_SIGMA	4
TUNING_TUNED_THRESHOLD_95_HIGH	1571.093
TUNING_TUNED_THRESHOLD_95_LOW	1434.24
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_TUNED_THRESHOLD_MEAN	1502.8
TUNING_TUNED_THRESHOLD_SIGMA	33
TUNING_TUNED_TOT_95_HIGH	7
TUNING_TUNED_TOT_95_LOW	7
TUNING_TUNED_TOT_MEAN	7
TUNING_TUNED_TOT_SIGMA	0
TUNING_UNTUNED_NOISE_95_HIGH	56.724
TUNING_UNTUNED_NOISE_95_LOW	28.283
TUNING_UNTUNED_NOISE_MEAN	42.026
TUNING_UNTUNED_NOISE_SIGMA	9.102
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2588.04
TUNING_UNTUNED_THRESHOLD_95_LOW	1510.524
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	3
TUNING_UNTUNED_THRESHOLD_MEAN	2007
TUNING_UNTUNED_THRESHOLD_SIGMA	274

Filename	Contents
0x14b45_MODULE/INITIAL_WARM_L2_warm.json	Download
output.log	Download
0x14b45.log	Download
20UPGFC0084805_MODULE__INITIAL_WARM_TUNING.zip	Download
